Mecc Alte LT3N-100/4 Alternator SAE 5 | SAE 6.5

MACHINE DESCRIPTION

LT3N Series alternators are single-phase brushless units. They operate highly reliably and do not require maintenance since they do not have slip rings or slipping contacts. LT3N alternators are made in compliance with the 2006/42, 2014/35, 2014/30, 2011/65, 2015/863 directives and their amendments and the EN 60034-1, CEI 2-3, IEC34-1, VDE 0530, BS 4999-5000, and N.F. 51.111 regulations.

The shaft is in C45 steel and is fitted with a keyed fan. The mechanical protection level meets standard IP21 (upon request higher levels of protection can be supplied). The H-class insulation and windings are impregnated with tropicalized epoxy resins. The standard generators comply with the basic safety requirements of the European regulation on electromagnetic compatibility; by applying the European standards 61000-6-3, EN61000-6-2, the above-mentioned regulation is complied with.
